There may be a long lead time for this product due to high demand

Laser Falcon is a very lightweight laser-type methane gas detector. The dramatically reduced weight of the product allows variety of new applications of the device including airborne methane monitoring and robotic instrumentation. This device can detect methane that exists about 100 meters away instantly. Measurement data is sent through a communication port and is backed up in a micro SD card. Power supply through the external power connector enables continuous operation of the device.

Laser Falcon is a compact and lightweight instrument that is easily integrated with most types of UAVs. Using the same measurement principle as the popular Laser Methane mini (LMm), the Laser Falcon remotely detects gas leaks utilizing laser technology. Much lighter than the LMm, this unit can be used in a variety of applications – including airborne methane monitoring and robotic instrumentation. This simple-to-use unit does a self-calibration check during the start-up process and needs no periodic maintenance. Measurement data is saved on a Micro SD card (included). It’s the perfect solution to difficult to survey areas; the Laser Falcon and your UAV save inspection time compared to a traditional walking gas leak survey.

UGCS SKYHUB

The onboard computer UgCS SkyHub is the key element that enables the full integration of the drone, laser methane detector, and ground control software UgCS. The UgCS SkyHub, designed by SPH Engineering, saves the gas detector's data in .csv format and transfers it instantly to the drone pilot's remote control and the desktop software UgCS. This way, the operator detects leaks in real-time and ensures faster response time.

The UgCS SkyHub also enables adding a radar altimeter to allow the flight in True Terrain Following mode: the drone (UAV) accurately follows the terrain during the flight, based on data received from the radar altimeter. True Terrain Following makes the drone fly at constant AGL altitude without importing a precise Digital Elevation Model (DEM) height-map into UgCS.

Specs

Item	Specifications
Gas to be measured	Methane (CH4) and methane-containing gases such as natural gas
Measurable Level	1 ～ 50,000 ppm-m
Measuring Accuracy	±10 %　1）
Measuring Speed	0.1 seconds
Measurable Distance	0.5 ~ 100 m　2）
Power Supply	External power (5V-18V)
Lase Safety Class	Guide light (Red laser light) : Class 2 Measurement light (infrared laser light) : Class 1
Operation temperature	-17 ～ 50 ℃
Dimensions, Mass	100(W) ×81(D) × 80(H) mm, 230g or less
Standard accessory	User manual, Carrying case, Micro-SD card (16GB) Power cable (1.5m, USB Type-A － Micro USB Type-B) PC cable (1.5m、 USB Type-A － Mini USB Type-B)

1）Accuracy measurement was performed at a target distance of 2m with a card-board reflector. Standard gas cells with 100ppm-m and 1,000ppm-m column densities were used.

2）Lowest detectable column density increases as detecting distance increases.

Guide of lowest measureable column density at various detecting distances
・ 30m ： 500ppm-m （ex :Methane of 5,000ppm with plume size of 10cm.)
・ 60m ：1,500ppm-m （ex :Methane of 1.5% with plume size of 10cm.)
・100m ：2,000ppm-m （ex :Methane of 2% with plume size of 10cm.)
