Equipped with an uprated Micro 4/3 sensor, the DJI Zenmuse X5S has a dynamic range of 12.8 stops with a much improved signal to noise ratio and color sensitivity than the X5R. Included here are the gimbal, camera, and lens. The new CineCore 2.0 image processing system on the Inspire 2 makes the Zenmuse X5S capable of capturing 5.2K 30fps CinemaDNG video and Apple ProRes video, as well as 4K 60fps using H.264 and 4K 30fps using H.265 (both at 100Mbps). Continuous DNG burst shooting at 20fps with 20.8MP images is also supported. The Zenmuse X5S was designedto keep pace with the rigors of high-end professional aerial imaging.

Dynamic range

SNR 18%

Color sensitivity

IMPROVED MICRO 4/3 SENSOR

The onboard Micro 4/3 sensor has been upgraded, significantly improving image quality. With a pixel size of 3.4?m, this 20.8-megapixel sensor captures more detail than the previous sensor. It has 12.8 stops of dynamic range as well as a better signal to noise ratio and color sensitivity than the X5R, allowing it to create clear, low noise images in low light environments.

ARRAY OF COMPATIBLE LENSES

Since it uses a standard Micro 4/3 mount, the Zenmuse X5S now supports up to eight professional lenses* with focal lengths ranging from 9mm-45mm (equivalent to 18mm-90mm on a 35mm camera), providing more creative control over the final look of a shot.

Olympus M.Zuiko 12mm/2.0
DJI MFT 15mm/1.7 ASPH
Olympus M.Zuiko 17mm/1.8
Panasonic Lumix 15mm/1.7
Olympus M.Zuiko 25mm/1.8
Panasonic Lumix 14-42mm/3.5-5.6 HD
Olympus M.Zuiko 45mm/1.8
Olympus M.Zuiko 9-18mm/4.0-5.6

*A balancing ring is needed for some lenses. More compatible lenses will be available.

[

HOLLYWOOD-GRADE VIDEO

Using CineCore 2.0, the Zenmuse X5S records video at a maximum resolution of 5.2K/30fps in CinemaDNG 12bit¹, 5.2K 30fps Apple ProRes 422 HQ and 4K 30fps Apple ProRes 4444 XQ (no alpha)². Additional recording options include video in 4K/60fps using H.264 or oversampling video in 4K/30fps using H.264/H.265, both with a bitrate of 100Mbps.¹²Additional licenses required

[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]

FAST, EFFICIENT WORKFLOWS

The DJI CINESSD card (PCIe3.0 NVMe SSD support) and a highly optimized FAT32/exFAT file system, allows Zenmuse X5Sfootage to be transferred directly through the DJI CINESSD STATION card reader to a computer at high speeds without anyadditional software. Footage also supports the DIT standard. CinemaDNG or Apple ProRes workflows can be used for post-processing.

[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]

ENHANCED CAMERA STABILIZATION

Stabilizing the Zenmuse X5S is a highly optimized 3-axis gimbal with pinpoint-precise motor rotation with a control accuracy of ±0.01° powered by a dedicated processor.Rather than rely on electrical slip rings — as is common with many gimbals — the Zenmuse X5S uses a unique mechanically limited design and concealed wires to ensuremore stable data transmission and greater durability. Vibration is eliminated using three damping balls and a lightweight damping board, creating seamlessly smooth video.360° rotation remains possible through gimbal rotation and smooth aircraft yaw. Stable, smooth footage¹ can be captured even when using a 90mm² lens.

¹ Equivalent to 35mm camera’s standard focal length² Exposure time must be equal to or longer than 1/60 in GPS mode

LOSSLESS IN-VIDEO SINGLE AND BURST PHOTO CAPTURE

Using only the Micro SD card, 20.8MP stills can be captured at 14fps in Burst Mode in JPEG DNG. Using the DJI CINESSD opens up 20fps continuous DNG Burst Mode with a maximum image resolution of 20.8 megapixels. Stills can also be taken during video recording without interruption.
